ACTIVE SPLITTERS

We offer a wide range of stand-alone and modular type active splitters for extended L-Band 850 – 2450MHz and IF 40 – 200MHz (other frequency ranges are available upon request). Our 1RU/19″ versions come with single 4-way, 8-way or 16-way splitter modules while also dual and quad variants are available. The modular and expandable systems (MFC/LSA, LSC series) have a capacity for up to 16 active splitter modules.

A perfect fit for operations where more accurate and stable RF power at the highest quality and availability is required are our splitters with integrated non redundant or 1+1 redundant operating line amplifiers coming with variable gain control and other functionalities (LSC series, HQS, RLS27xxA…).

Many beneficial features such as RF power monitoring, LNB-supply, 10MHz reference feed, local and remote monitoring and configuration as well as 1:1 redundant dual power supply are either included by standard or optionally available.

Don´t find what suites your requirements?
Please contact us for custom-made product solutions according to your specific demands and application.

RF-Design Ecoline LCEL + LSEL

LSEL Ecoline

Extended L-Band Active Splitters
(4-way, 8-way, 16-way)

RF-Design Baseline Front

LSA Baseline

Modular Active L-Band Splitters
(4-way, 8-way, 16-way)

RF-Design Baseline Front

ISA Baseline

IF Active Splitters
(8-way, 16-way)

RF-Design Baseline IFSA116R-50S

IFSA Baseline

IF Active Splitters with redundant Amplifiers
(16-way)

RF-Design HQS125CR-32 Front

HQS125CR-32

1+1 redundant L-Band Line Amplifiers with Splitters (max. 1:32)

RF-Design HQS Series Front

HQS Series

L-Band Line Amplifiers with internal 1:8 or 1:16 Splitters

RF-Design RLC2716A Front

RLS2708A / RLS2716A

1+1 redundant L-Band Line Amplifiers with internal 1:8 and 1:16 Splitters

RF-Design MFC416

MFC/LSA

Modular active L-Band Splitters, 1:4, 1:8, 1:16 (*upon request only)

RF-Design LSCX414

LSCX414

4-way Active L-Band Splitter/Combiner TX/RX System

RF-Design LSC408 L-Band Splitter-Combiner

LSC Series

Modular 8-way L-Band Splitter/Combiner System with 1:1 redundant Amplifier
