SWITCH MATRIX SOLUTION

RF-Design Switch/Routing Matrix solutions are available in different sizes and configurations as full fan-out/distributive or full fan-in/combining systems covering L-Band (950 – 2150MHz) and extended L-Band (850 – 2450MHz) frequencies and coming as stand-alone units or as expandable systems. All our Switch Matrix units are excellently suited for flexible RF signal distribution applications e.g. in Teleports, Satellite Earth-Stations, DSNG vehicles, Broadcast stations and other applications.

Our Switch/Routing Matrix systems are distinguished by excellent RF performance, operational stability and come with lots of features such as hot-swappable active components, switchable LNB-supply, variable gain control, RF power-monitoring and other beneficial functionalities.

We also have the flexibility to develop and to manufacture custom-made Switch/Routing matrix systems.

RF-Design FlexLink R25 Front

FlexLink R25

Extended L-Band Switch Matrix System Eco and Pro Version 64:64

RF-Design FlexLink K7

FlexLink K7-Pro

Extended L-Band Switch Matrix 8:8 – 64:64
(fan-out/distributive)

RF-Design FlexLink K4 Switch Matrix

FlexLink K4

Extended L-Band Switch Matrix 4:4 – 32:32
(fan-out/distributive)

RF-Design Product FlexLink K73 Switch Matrix Front

FlexLink K73S

L-Band Switch Matrix 8:8 – 128:16
(fan-out/distributive)

FlexLink S9E-1616

Extended L-Band Switch Matrix 16:16
(fan-out/distributive)

RF-Design Product FlexLink S9E-1608 Switch Matrix Front

FlexLink S9E-1608C

Extended L-Band Switch Matrix 16:8
(fan-in/combining)

RF-Design FlexLink S9E-88 Switch Matrix

FlexLink S9E-88

Extended L-Band Switch Matrix 8:8
(fan-out/distributive)

RF-Design FlexLink S9E-88C Switch Matrix

FlexLink S9E-88C

Extended L-Band Switch Matrix 8:8
(fan-in/combinig)

RF-Design FlexLink S9E-88X Hybrid Switch Matrix

FlexLink S9E-88X Hybrid

Extended L-Band Hybrid Switch Matrix 2 x 8:8
(distributive & combining)

FlexLink S2B

L-Band Switch Matrix 8:24
(fan-out/distributive)

RF-Design Product S92E-3232 Switch Matrix Front

FlexLink S92E-3232

IF Switch Matrix 32:32, 40 – 200MHz
(fan-out/distributive)
