HQR245C-FT
1+1 redundant / 2 single high precision L-Band Amplifier
The HQR245C-FT represents a 1+1 redundant RF line amplifier in a compact 1RU/19″ rack mount operating at L-Band (950 – 2150MHz) frequency useable as 1+1 or dual single operational amplifier. It comes with variable gain control ranging from 0 to 40dB in 0,1dB step along with slope equalization (module HQA45MGFT) and various additional functionalities. For highest operational performance the HQR245C-FT is available with Amplifier Module HQA45MGFTNS (no slope) for highest return loss > 18dB …
FlexLink R25
Switch Matrix System
The FlexLink R25-Eco represents a unique, innovative & clever L-Band Switch Matrix system, built into a 5RU/19″ rack mount chassis with only 500mm depth. It performs as a scalable distributive switch/routing platform allowing to switch/route any selected input to any or all outputs and can be assembled with various input/output configurations from 8:8 to 64:64 in one matrix chassis.
FiberLink2plus
Dual Channel RF-over-Fiber System
The FiberLink2plus incorporates 1RU/19” and 3RU/19” rackmount chassis with capacity for maximum 4 or 16 dual optical TX and/or RX modules and the corresponding optical TX and RX modules available for various RF frequency ranges. It allows distribution of up to 32 RF signals over optical fiber and besides its modular and high-density design, it also offers premium quality and many beneficial features.
RF-Design ́s Switch Matrix, RF-over-Fiber, Line Amplifier and RF Monitoring Solutions. You can find the article on page 26.
Another job successfully done in cooperation with our partner Vincor LTD. Five LSC chassis each fully populated with modular type 8-way splitters/combiners and 1:1 redundant ...
Here our HQR145C 1:1 redundant line amplifiers during final test run shortly before dispatch to Mexico for an AXESS Networks ground station. Learn more ...
Introducing the improved QLink Quad RF-over-Fiber system, now modular and field expandable - more features, flexibility and application scope ...
Some of our EcoLine active L-Band splitters ready for operation at a leading global media services company in the Netherlands. A big THANK YOU goes to our sales partner Toner Cable ...
Some RLA270A 1+1 redundant L-band Line Amplifieres during the burn-in test ready to be shipped to Intelsat for deployment at several of their ground stations around the globe...
Satellite Innovation — RF-DESIGN to spotlight their RF family of products
Another highlight at IBC is our innovative N+1 redundant Line amplifier HQR445C. Visit our booth and learn more about this ...
Read the WTA Member News about our 40GHz Dual RF Power Meter.
See more at
We look very much forward to meeting with you at our stand and to presenting our latest product innovations as well as to talking about your individual requirements with you at these upcoming events
For meeting requests during the show please send an e-mail to contact@rf-design-online.de
